| MODEL | Type | Unit Match or Number of Zones | Clg Cap MBtuH | SEER | Htg Cap MBtuH | HSPF | Refrigerant Connections | Dimensions HxWxD | Weight | CFM RANGE | SOUND DB | MAX PIPE LENGTH FT. | MAX PIPE HEIGHT |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FTXN09KEVJU | Indoor | RXN09KEVJU | 9.0 | 14.5 | 10.0 | 8.5 | 1/4 - 3/8 | 11.1x30.3x7.7 | 16 | 187-342 | 22-40 | 65.6 | 49.2 |
| FTXN12KEVJU | Indoor | RXN12KEVJU | 12.0 | 14.0 | 13.5 | 8.5 | 1/4 - 3/8 | 11.1x30.3x7.7 | 16 | 201-357 | 23-42 | 65.6 | 49.2 |
| FTXN15KVJU | Indoor | RXN15KEVJU | 15.0 | 14.5 | 18.0 | 8.5 | 1/4 - 1/2 | 11.5x41.3x9.4 | 27 | 360-568 | 33-45 | 98.2 | 65.6 |
| FTXN18KVJU | Indoor | RXN18KEVJU | 18.0 | 14.5 | 21.6 | 8.5 | 1/4 - 1/2 | 11.5x41.3x9.4 | 27 | 403-614 | 33-45 | 98.2 | 65.6 |
| FTXN24KVJU | Indoor | RXN24KEVJU | 22.0 | 14.5 | 24.0 | 8.5 | 1/4 - 1/2 | 11.5x41.3x9.4 | 27 | 403-614 | 34-46 | 98.2 | 65.6 |
| RXN09KEVJU | Outdoor | FTXN09KEVJU | 9.0 | 14.5 | 10.0 | 8.5 | 1/4 - 3/8 | 21.7x25.9x10.7 | 68 | ||||
| RXN12KEVJU | Outdoor | FTXN12KEVJU | 12.0 | 14.0 | 13.5 | 8.5 | 1/4 - 3/8 | 21.7x25.9x10.7 | 68 | ||||
| RXN15KEVJU | Outdoor | FTXN15KVJU | 15.0 | 14.5 | 18.0 | 8.5 | 1/4 - 1/2 | 23.4x31.3x11.8 | 93 | ||||
| RXN18KEVJU | Outdoor | FTXN18KVJU | 18.0 | 14.5 | 21.6 | 8.5 | 1/4 - 1/2 | 23.4x31.3x11.8 | 93 | ||||
| RXN24KEVJU | Outdoor | FTXN24KVJU | 22.0 | 14.5 | 24.0 | 8.5 | 1/4 - 1/2 | 23.4x31.3x11.8 | 93 |
